SOUTHERN CONDOR – TECHNICAL SPECIFICATION


Principal Particulars

Type: Roll on / Roll off (Stern Loading Vessel)
Official Number: 857011
Call Sign: VJT6195
MMSI No.: 50343600
Flat: MAST with AMSA accreditation
Classification: USL Class 2B
Year Built: 2002
GRT/NRT: 247/500
DWT: 286
Accommodation: 10 Persons

Dimensions

Length overall: 34.95m
Breadth Moulded: 10.8 m
Depth Moulded: 3.0m
Draft Loaded: 2.1m – 275 Tonne on deck/ full fuel and water
Light Draft: 1.1m
High ABV W/L: 0.9m

Capacity

Fuel Oil: 20,000 L
Fresh Water: 5,000 L
Diesel Fuel Cargo: 50,000 L in Stern Tank
Port & Starboard Ballast Tanks: 50,000 L, can be converted to fuel

Performance

Speed Max / Econ: 10 knots / 8.5 knots
Fuel Oil consumption: 160 L per hours, at 1600RPM
RPM: 2 x 1800
Genset: 150 L per day

Machinery and Equipment

Main Engine: 2 x Cummins KTA – 19m Diesel Engines
Horse Power: 2 x 435kw
Anchor windless: Hydraulic
Propeller: Fixed
Cummings Gensets: 2 x 60 KVA

Navigation & Communication

Nav. Equipment: Radar, GPS / plotters
Communication: GMDSS, VHF, HF, UHF, SSB, Intercom, Satellite & Mobile Phone

Passengers

12 day accommodation only – can convert to cabins x4
Vessel dry docked August 2011 full hull and shaft surveys
Antifoul Seapro CU120 DNV Certified


Download Safety Plan and Floor Plan PDF
